Power: 14.5kW
Thrust(Forward/Backward): 165kg/165kg
Rated speed: 1150r/min
Technical Parameters
| Rated voltage: | 300VDC |
| Housing: | Aluminum alloy / Titanium alloy |
| Rotation direction: | Left-hand / Right-hand |
| Propeller material: | Stainless steel |
| Temperature: | Storage temperature: -40~70℃, working temperature: -5~40℃ |
| Sealing form: | Zero penetration magnetic coupling rotary seal structure |
| Working water depth: | 0-850m/0-1500m/0-3000m/0-6000m/Full sea depth.Working water depth>850m, Oil-filled seal |
| Drive: | Built-in (0-1500m)/External |
| Signal power supply: | 无 |
| Control mode/speed feedback: | Analog voltage (pulse feedback/analog voltage feedback), PPM, RS485, CAN |
● Selection Parameters
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe. Please consult technical personnel for details.
● Product Features
Suitable for AUV vertical, horizontal thruster, and ROV
