Power: 980 W
Forward Thrust: 19 kg
Backward Thrust: 19 kg
Technical Parameters
| Rated speed: | 1900r/min |
| Rated voltage: | 48VDC/60VDC/72VDC/100VDC/120VDC/160VDC/200VDC/250VDC/300VDC |
| Housing: | Aluminum alloy / Titanium alloy |
| Rotation direction: | left-hand right-hand |
| Propeller material: | Stainless steel |
| temperature: | Storage temperature: -40~70℃, working temperature: -5~40℃ |
| Sealing form: | Zero penetration magnetic coupling rotary seal structure |
| Working water depth(m): | 0-850/0-1500/0-3000/0-6000/Full sea depth Working water depth>1500m. Oil-filled seal |
| Drive: | Built-in (0-1500m)/external |
| Signal power supply: | 12VDC (±5%), ≤ 250mA |
| Air deflector: | Black |
| Control mode/speed feedback: | Analog voltage (pulse feedback/analog voltage feedback) PPM RS485 CAN |
● Selection parameters
| Working water depth | Outline ruler (mm) | Length(mm) | Air weight (kg) | Weight in water (kg) | Connector model | Optional voltage levels |
0-850 & 0-1500 | φ172.5 | 315.8 | 2.9~3.1 | 1.7~2.0 | MCBH8M | 48~300VDC |
| 0-3000 & 0-6000 | φ172.5 | 273.9 | 3 | 2.0 | MCPBOF8M | Tube O.D. 3/4'' Tube Bend OD 3'' |
| Total depth | φ172.5 | 273.9 | 3 | 2.0 | PBOF8M |
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe. Please consult technical personnel for details.
● Advantage
Applicable to:
Small and medium-sized ROV
Feature:
Its spiral blades are symmetrical and have balanced forward and Backward Thrust. The T540S underwater thruster has a speed closed-loop function, which has become a major highlight of this product. When multiple devices are used simultaneously, this function ensures that the speed accuracy of each device reaches ± 10rpm, meeting the requirement of high consistency.
