Power: 1000 W
Forward Thrust: 15kg
Backward Thrust: 15kg
Technical Parameters
| Rated speed | 2500r/min |
| Rated voltage | 48VDC/60VDC/72VDC/100VDC/120VDC/150VDC/200VDC/230VDC/260VDC/300VDC |
| Housing | Aluminum alloy /Titanium alloy |
| Rotation direction | left-hand right-hand |
| Propeller material | Stainless steel |
| temperature | Storage temperature -40~70℃, working temperature -5~40℃ |
| Sealing form | Zero penetration magnetic coupling rotary seal structure |
| Working water depth(m) | 0-850/0-1500/0-3000/0-6000/Full sea depth Working water depth>1500m. Oil-filled seal |
| Drive | Built-in (0-1500m)/external |
| Signal power supply | 12VDC (±5%), ≤ 250mA |
| Air deflector | Black |
| Control mode/speed feedback | Analog voltage (pulse feedback/analog voltage feedback) PPM RS485 CAN |
| Working water depth | Outline ruler (mm) | Length(mm) | Air weight (kg) | Weight in water (kg) | Connector model | Optional voltage levels |
0-850 & 0-1500 | φ151.8 | 315.8 | 2.5~2.9 | 1.7~1.9 | MCBH8M | 48~300VDC |
| 0-3000 & 0-6000 | φ151.8 | 273.9 | 3.5 | 2.4 | MCPBOF8M | Tube O.D. 3/4'' Tube Bend OD 3'' |
| Total depth | φ151.8 | 273.9 | 3.5 | 2.4 | PBOF8M |
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe. Please consult technical personnel for details.
● Advantage
Applicable to:
Small and medium-sized ROV.
Feature:
The T530 underwater thruster requires frequent forward and reverse switching. Therefore, multiple optimizations have been made in the selection of bearing materials, back electromotive force control, protection function, and internal slope control, making the thruster smoother in the forward and reverse switching process, improving reliability and durability.
