Power: 400 W
Forward Thrust: 7.3 kg
Backward Thrust: 7.3 kg
Technical Parameters
| Rated Speed | 2480 r/min |
| Rated Voltage | 32VDC/48VDC/65VDC/80VDC/100VDC/150VDC/200VDC/250VDC/300VDC |
| Motor Compartment | Aluminum alloy (0-850m)/Titanium alloy |
| Rotation Direction | Left-hand, Right-hand |
| Propeller Material | Stainless steel |
| Temperature | Storage temperature: -40~70℃ Working temperature: -5~40℃ |
| Sealing Form | Zero penetration magnetic coupling rotary seal structure |
| Working Water Depth | 0-850m/0-1500m/0-3000m/0-6000m/Full sea depth Working water depth >1500m: Oil-filled seal |
| Drive | Built-in (0-1500m)/External |
| Signal Power Supply | 12VDC (±5%), ≤ 210mA |
| Air Deflector | Black |
| Control Mode/Speed Feedback | Analog voltage (Pulse feedback/Analog voltage feedback), PPM, RS485, CAN |
● Advantage
Applicable to：
Small ROV
Feature：
Its uniqueness lies in the synchronous design of the propeller and nozzle, which makes the helical blades symmetrical and the forward and reverse thrust balanced. The nozzle provides a 13% increase in thrust for propulsion, resulting in excellent performance in both vertical and horizontal propulsion. Simultaneously equipped with speed closed-loop function, when multiple devices are used simultaneously, it can ensure that the speed accuracy of each device reaches ± 10rpm, meeting the requirements of high consistency.
● Selection Parameters
| Working water depth | Outline ruler (mm) | Length(mm) | Air weight (kg) | Weight in water (kg) | Connector model | Optional voltage levels |
| 0-850 & 0-1500 | φ130 | 252 | 1.3~1.5 | 1.0 | MCBH8M | 48~300VDC |
| 0-3000 & 0-6000 | φ130 | 252 | 2.1 | 1.4 | MCPBOF8M | Tube O.D. 3/4'' Tube Bend OD 3'' |
| Total depth | φ130 | 252 | 2.1 | 1.4 | PBOF8M |
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe. Please consult technical personnel for details.
