Rated Power: 490W
Forward Thrust: 6.7kg
Backward: 6.7kg
Technical Parameters
| Rated Power | 490W |
| Forward/Reverse Thrust | 6.7kg |
| Max RPM | 2300 r/min |
| Rated Voltage | 32VDC/48VDC/65VDC/80VDC/100VDC/130VDC/150VDC/200VDC/250VDC/300VDC |
| Control Signal/Feedback Signal | Analog voltage control, CAN, Pulse feedback, RS485 |
| Direction of Rotation | Right-hand or Left-hand |
| Working Water Depth | 0-850m/0-1500m/0-3000m/0-6000m/Full sea depth Working water depth >1500m: Oil-filled seal |
| Housing | Alloy or Titanium |
| Weight | 1747g |
| Length | 236mm |
| Maximum Outer Diameter | 115mm |
| Speed Feedback Description | According to the communication protocol, returns data as 2 bytes of hexadecimal data, unit is r/min |
● Selection Parameters
| - | Rating |
| Forward Thrust | 6.7Kg |
| Reverse thrust | 6.7Kg |
| Forward speed | 2300rpm |
| Reverse RPM | 2300rpm |
| Forward power | 490W |
| Reverse power | 490W |
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe. Please consult technical personnel for details.
● Advantage
Applicable to:
Small ROV or AUV with a diameter of over 300mm.
Feature:
Its design is unique, with symmetrical blades and equal forward and reverse thrust. Its speed closed-loop function ensures that the speed accuracy of each device reaches ± 10rpm when multiple devices are used simultaneously, thus meeting the requirement of high consistency.
