Power: 400W
Materials: Aluminum alloy/Titanium alloy
Operating water depth: 0-50m/Full ocean depth
Technical Parameters
| Rated voltage | 24VDC/48VDC/70VDC/85VDC/100VDC/150VDC/200VDC/250VDC/300VDC |
| Temperature | Storage temperature: -40 °C to 70 °C. Operating temperature: -5 °C to 40 °C. |
| Rated speed-torque | 80 revolutions per minute - 25N·m, 40 revolutions per minute - 50N·m, 25 revolutions per minute - 80N·m, 50 revolutions per minute - 40N·m, 30 revolutions per minute - 60N·m, |
| Driver | Built-in |
| Signal power supply | 12VDC (± 5%), with a current ≤ 250mA |
| Control mode/speed feedback | Analog voltage (pulse feedback/analog voltage feedback), PPM, RS485, CAN |
