Power: 400W
Materials: Aluminum alloy/Titanium alloy
Operating water depth: 0 - 50m/Full ocean depth
Technical Parameters
| Rated voltage | 24VDC/48VDC/70VDC/85VDC/100VDC/150VDC/200VDC/250VDC/300VDC |
| Operating water depth | 0 - 50m/Full ocean depth |
| Materials | Aluminum alloy/Titanium allo |
| Temperature | Storage temperature: -40 to 70 °C. Operating temperature: -5 to 40 °C |
| Rated speed-torque | 80 revolutions per minute - 25N·m, 40 revolutions per minute - 50N·m, 25 revolutions per minute - 80N·m, 50 revolutions per minute - 40N·m, 30 revolutions per minute - 60N·m |
| Driver | Built-in |
| Signal power supply | 12VDC (± 5%), ≤ 250mA |
| Control mode/speed feedback | Analog voltage (pulse feedback/analog voltage feedback), PPM, RS485, CAN |
