Power: 2kW
Forward Thrust: 20kg
Backward Thrust: 20kg
Technical Parameters
| Power: | 2kw |
| Control Signal: | CAN |
| Feedback Signal: | CAN |
| Rated voltage: | 300V |
| Direction of rotation: | Left-handed or right-handed |
| Working depth: | 6000m |
| Casing: | aluminum alloy |
| Weight: | 13434g |
| Length: | 141mm |
| Maximum outer diameter: | 276mm |
● Selection Parameters
| - | Rating |
| Forward Thrust | 20.0Kg |
| Reverse thrust | 20.0Kg |
| Forward speed | 1500rpm |
| Reverse RPM | 1500rpm |
| Forward power | 2000W |
| Reverse power | 2000W |
Note: The weight change of oil-filled compensation products is affected by the length of the oil pipe, please consult the technical personnel for details.
● Product Features
Rim Drive Propulsion integrates the motor rotor and blades into one unit, eliminates the traditional through cabin propulsion shaft system and sealing system, and uses direct power transmission through electrical energy, thus occupying almost no cabin space.
The blade support structure is placed inside the guide tube, which correspondingly increases the flow area inside the guide tube and improves the propulsion efficiency.
