Rated Voltage/Current：150V / 40Ah
Input Voltage Range：118V - 180VDC
Rated Power：6KW
Technical Parameters
Parameters of electric outboard engines
| Rated Voltage/Current | 150V / 40Ah |
| Input Voltage Range | 118V - 180VDC |
| Rated Power（Forward/Reverse） | 6KW / 6KW |
| Thrust | 120kg |
| Full-load rotational speed (forward direction) | 1560rpm |
| Control | Control box |
| Net Weight | 17kg |
| Communication | CAN BUS |
| Length×Width×Height(mm) | 467×300×597 (mm) |
| Axis Length(mm) | 298mm |
| Angle of Lifting | / |
| Max Lifting Angle | / |
| Propeller diameter | 300mm |
| Operating Temperature / Storage Temperature | -10℃ to 40℃ / -20℃ to 60℃ |
