Rated Voltage/Current：48V / 32Ah
Input Voltage Range：35V - 60VDC
Rated Power：1.5KW
Technical Parameters
|
| |
| Outboard | With tiller | |
| Rated Voltage/Current | 48V / 32Ah | |
| Input Voltage Range | 35V - 60VDC | |
| Rated Power(Forward/Reverse) | 1.5KW / 1.5KW | |
| Equivalent Fuel Outboard | 4hp | |
| Maximum Efficiency of the Whole Machine | 56% | |
| Full Load Speed(Forward) | 1200rpm | |
| Control | Tiller/Control Box | Tiller |
| Communication | CAN BUS | |
| Length×Width×Height(mm) | 505×240×1259 (mm) | 1028×240×1259(Long shaft) 1028×240×1134(Short shaft) |
| Axis Length(mm) | 750mm | 750mm(Long shaft) 625mm(Short shaft) |
| Net Weight | 16kg(Without Battery) | 16.5kg(Without Battery) |
| Angle of Lifting | 0°/ 7° / 14° / 21° / 65° | |
| Max Lifting Angle | 65° | |
| Popeller Diameter | 291mm | |
| Operating Temperature/Storage Temperature | -25℃ to 50℃ / -13℉ to 122℉ | |
