Rated Voltage/Current：350V / 114Ah
Input Voltage Range：280V - 460VDC
Rated Power：40KW
Technical Parameters
| Rated Voltage/Current | 350V / 114Ah |
| Input Voltage Range | 280V - 460VDC |
| Rated Power(Forward/Reverse） | 40KW / 32KW |
| Equivalent Fuel Outboard | 70hp |
| Maximum Efficiency of the Whole Machine | 60% |
| Full Load Speed(Forward) | 1800rpm |
| Control | Control Box |
| Communication | CAN BUS |
| Length×Width×Height(mm) | 909×385×1661 (mm) |
| Axis Length(mm) | 824mm |
| Net Weight | 110kg |
| Angle of Lifting | 0°/ 15° / 30° / 45° / 60° |
| Trim and Tilt | Power trim/tilt |
| Popeller Diameter | 16"×11“ 15”×10 3/4“ |
| Operating Temperature/Storage Temperature | -25℃ to 50℃ / -13℉ to 122℉ |
