Rated Voltage/Current：150V / 40Ah
Input Voltage Range：117V - 182VDC
Rated Power ：6KW
Technical Parameters
|
| |
| Outboard | With tiller | |
| Rated Voltage/Current | 150V / 40Ah | |
| Input Voltage Range | 117V - 182VDC | |
| Rated Power(Forward/Reverse) | 6KW / 6KW | |
| Equivalent Fuel Outboard | 12hp | |
| Maximum Efficiency of the Whole Machine | 56% | |
| Full Load Speed(Forward) | 1560rpm | |
| Control | Tiller/Control Box | Tiller |
| Communication | CAN BUS | |
| Length×Width×Height(mm) | 603×300×1208 (mm) | 1100×300×1208(mm) |
| Axis Length(mm) | 736mm | 736mm |
| Net Weight | 31kg | 31kg |
| Angle of Lifting | 0°/ 15° / 30° / 45° / 60° | |
| Max Lifting Angle | 60° | |
| Popeller Diameter | 300mm | |
| Operating Temperature/Storage Temperature | -25℃ to 50℃ / -13℉ to 122℉ | |
