Rated Voltage/Current：96V / 105Ah
Input Voltage Range：82V - 108VDC
Rated Power：10KW
Technical Parameters
| Rated Voltage/Current | 96V / 105Ah |
| Input Voltage Range | 82V - 108VDC |
| Rated Power(Forward/Reverse） | 10KW / 9KW |
| Equivalent Fuel Outboard | 18hp |
| Maximum Efficiency of the Whole Machine | 56% |
| Full Load Speed(Forward) | 1300rpm |
| Control | Control Box |
| Communication | CAN BUS |
| Length×Width×Height(mm) | 713×361×1386 (mm) |
| Axis Length(mm) | 742mm |
| Net Weight | 68kg |
| Angle of Lifting | 0°/ 15° / 30° / 45° / 60° |
| Trim and Tilt | Power trim/tilt |
| Popeller Diameter | 320mm |
| Operating Temperature/Storage Temperature | -25℃ to 50℃ / -13℉ to 122℉ |
