Input power: 600W / 8kW
Forward thrust: 180kgf
Rated voltage: 48VDC / 300VDC
Technical Parameters
| Rotary actuator | Propeller | |
| Input power | 600W | 8kW |
| Rated voltage | 48VDC | 300VDC |
| Rated torque | 100 Nm | / |
| Rated speed | 4 rpm | 1200rpm |
| Rated thrust | / | 180kgf |
| Enclosure material | Aluminum alloy | |
| Sealing form | Zero - penetration magnetic coupling rotary sealing structure | |
| Working water depth | 0 - 100 m | |
| Rotation position feedback type | Encoder | |
| Angle range | 0° - 90° | |
| Rotation accuracy | 0.5° | |
| Driver | External | |
| Control mode / Speed feedback | CAN | |
