Battery capacity /kilowatt - hour：83.4kWh
Output Voltage Range：240-408V
Rated Voltage：347.5V
Technical Parameters
| Battery capacity /kilowatt - hour | 83.4kWh（96S240 Ah） |
| Battery Type | Solid State Lithium-Ternary Battery（NCM) |
| System Dimensions | 1385×1284×896 mm |
| Output Voltage Range | 240-408V |
| Rated Voltage | 347.5V |
| Maximum Sustainable Discharge Current | 240A |
| Peak Discharge Current | 800A / 10s |
| Standard Charging Current | 76A |
| Working Environment Temperature (Charge and Discharge) | -10〜60℃ |
| Working Sea Height | ≤3000 |
| Thermal Management | Natural Air Cooling |
| EMS | With Local EMS Control System |
| Weight（kg） | Approx. 750kg |
| Operating Noise | ≤70dB |
| Human-Computer Interface | LCD touch screen |
