Rated Voltage / Capacity：76.8V / 100Ah
Rated Energy：7680Wh
Battery Weight：69kg
Technical Parameters
| Rated Voltage / Capacity | 76.8V / 100Ah |
| Rated Energy | 7680Wh |
| Battery Size | 450×700×190 mm |
| Battery Weight | 69kg |
| Charging Voltage | 86.4V |
| Discharge Cutoff Voltage | 62.4V |
| Standard Charging Current | 15A |
| Max Charging Current | 50A |
| Max Sustainable Discharge Current | 100A |
| Series Connection | Not Support |
| Parallel Connection | Support |
| Storage Temperature | - 20 ～60℃ |
| Charging Temperature | 0 ～55℃ |
| Discharge Temperature | - 10 ～55℃ |
| Protection Level | IP65 |
| Suggested Storage Capacity | 45％～50％ |
| Cycle Life | ＞ 4000 Times |
