Rated Energy：11.04kWh
Dimensions：640×480×328 mm
Weight：85kg±2kg
Technical Parameters
| Applicable Model | 1.5kW and other products with a 48V voltage platform |
| Rated Energy | 11.04kWh |
| Dimensions | 640×480×328 mm |
| Weight | 85kg±2kg |
| Charging Voltage | 52.5V |
| Discharge Cut-off Voltage | 43.5V |
| Standard Charging Current | 50A |
| Maximum Charging Current | 230A |
| Maximum Continuous Discharge Current | 230A |
| Series Connection | / |
| Parallel Connection | Can |
| Storage Temperature | - 20 ～45℃ |
| Charging Temperature | 0 ～55℃ |
| Discharging Temperature | - 20 ～55℃ |
| IP Rating | IP67 |
| Storage Capacity | 50％ SOC |
| Cycle Life | ≤ 3500 Cycles |
