Rated Voltage: 144VDC(112V-168V)
Signal power: 24VDC（24V-33.6V）
Communication methods: CAN
Technical Parameters
| Material: | aluminum |
| Power rating: | 720W |
| Rated torque: | 3.7N·m |
| Rated RPM: | 1600rpm |
| Rated Voltage: | 144VDC(112V-168V) |
| Signal power: | 24VDC（24V-33.6V） |
| System external dimensions: | Ø312mm×670mm |
| Depth of work: | 0~850m |
| Sealed construction: | Magnetic Coupling Seal |
| Propeller rotation: | right-hand side |
| Storage temperature range: | -25～+70℃ |
| Operating temperature range: | -5～40℃ |
| Drive power: | 1200W |
| Communication methods: | CAN |
